Bridge Rectifiers | Status : Active

MBL6S

  • Package Type:MBLS-1
  • Packing Info: Tape&Reel: 4Kpcs/Reel;
  • Category:Bridge Rectifiers
Check Stock Add To Cart
Datasheet ECAD Model

Product Detail

Part Number Number of Functions IF(AV)(A) VRWM (V) VF
(V) [max]@IF(A)		 IR (uA)  [max] @
VR		 IFSM (A) IF(A) VR (V) Tj [max] (°C)
MBL6S 1-Phase Bridge 0.5 600 1.0 5.0 35 0.4 600 150
Part Number MBL6S Number of Functions 1-Phase Bridge IF(AV)(A)  0.5 VRWM (V)  600 VF
(V) [max]@IF(A)  1.0 		IR (uA)  [max] @
VR  5.0 		IFSM (A)  35 IF(A)  0.4 VR (V)  600 Tj [max] (°C)  150

Packing Information

Part Number Package Type Packing Specification Component Weight (g) Marking Code Packing Info
MBL6S MBLS-1 MBLS-1 0.0850 BL6S Tape&Reel: 4Kpcs/Reel;

Environmental Information link icon

Reliability Report Material Composition Data Sheet Soldering Profile Environmental Compliance
Configuration image Download Configuration image Download Configuration image Download Environmental Compliance Download
Tin Whisker Test Report
Tin Whisker Test Report
