Standard Recovery Power Modules | Status : Active

MD200C08D2

Check Stock Add To Cart
Datasheet ECAD Model

Product Detail

Part Number Number of Functions VRRM (V) IF(AV)(A)@Tc (°C) IFSM (A) VFM (V) IF(A) IRD (mA) VRD (V) Tc (°C) TVj [max] (°C)
MD200C08D2 Dual 800 200 6800 1.3 300 9 800 95 150
Part Number MD200C08D2 Number of Functions Dual VRRM (V)  800 IF(AV)(A)@Tc (°C)  200 IFSM (A)  6800 VFM (V)  1.3 IF(A)  300 IRD (mA)  9 VRD (V)  800 Tc (°C)  95 TVj [max] (°C)  150

Packing Information

Part Number Package Type Packing Specification Component Weight (g) Marking Code
MD200C08D2 D2 D2 160.0000 MD200C08D2

Environmental Information link icon

Reliability Report Soldering Profile Environmental Compliance
Configuration image Download Configuration image Download Environmental Compliance Download
